Jinan diesel engine JICHAI POWER G12V190PZL1 12V190 series drilling engine
  • name
  • name
  • name

Jinan diesel engine JICHAI POWER G12V190PZL1 12V190 series drilling engine

MOQ: 1
Price: 356
Standard Packaging: WOODEN CASES
Delivery Period: 5-8 DAYS
Payment Method: Western Union,MoneyGram,T/T
Supply Capacity: 457
Detail Information
Product Description
Detail Information
Place of Origin
CHINA
Brand Name
JDEC
Certification
CE
Model Number
12V190
Product Description
Model NO.
G12V190ZL1
Ignition Mode
Compression-Ignition
Speed
High Speed
Cooling Cylinder
Water-Cooled
Intake Pressure Impulse
Turbocharged
Piston Movement
Reciprocating
Fuel
Diesel
Number of Strokes
Four-Stroke
Cylinder Arrangement Form
V
Number of Cylinders
12-Cylinder
Type
Combustion Engine
Model
G12V190zl1
Rated Power (Kw/HP)
600
Rated Speed (Rpm)
1000
Cylinder Bore (mm)
190
Piston Stroke (mm)
210
Displacement (L)
71.45
Compression Ratio
14:1
Stable Rate (%)
Less Than 8
Fuel Consumption (G/Kwh)
Less Than 209.4
Oil Consumption (G/Kwh)
Less Than 1.6
Starting Method
Air Start or Electrical Start
Outline Size (Lxwxh) (mm)
2692X1560X2070
Net Weight (Kg)
5300
Transport Package
Wooden Box
Trademark
CHIDONG
Origin
China
HS Code
8408100000
Production Capacity
50000 Sets Per Year




Jinan diesel engine JICHAI POWER G12V190PZL1 12V190 series drilling engine 0Product Description

Features of 2000 series diesel engines

1. Improved fuel economy: compared with our first generation, it offers up to 10 g/kw.h in terms of fuel economy

2. Increased power output: it provides up to 120kW than the first generation

3. Low noise level and stability

4. Reasonable structure, simple maintenance

APPLICATIONS

This powerful engine can be used in torque converter sets or diesel generating sets to drive drilling rigs, mud pumps, fire pumps etc.

Diesel Engine Specification
Model G12V190ZL1
Rated power (kW) 1000
Rated speed (rpm) 1500
Type 4-stroke, direct injection combustion chamber, water-cooled, exhaust gas turbocharged, inlet air inter cooling
No. and layout of cylinders 12-cylinder, V shape, 60° angle
Cylinder bore (mm) 190
Piston stroke (mm) 210
Displacement (L) 71.45
Compression ratio 14:1
Fuel consumption (g/kWh) ≤209.4
Oil consumption (g/kWh) ≤1.6
Exhaust temp before turbine (ºC) ≤600
Water temperature (ºC) ≤90
Oil temperature (ºC) ≤95
Stable rate (%) ≤8
Cooling method Pressurized water cooling
Start mode Electric motor start
Lubricating Press and spray lubrication
Dimension (mm) 2692x1560x2070
Net weight (kg) 5300


Jinan diesel engine JICHAI POWER G12V190PZL1 12V190 series drilling engine 1

Item Name

  1. Flywheel 20GJ.30.12A

  2. Crankshaft 12VB.02.00

  3. Rear Electrical Assembly Z12VB.06.30.01

  4. Rear Electrical Assembly Z12VB.06.30.02

  5. Vibration Damper 129.22.00B

  6. Camshaft 12VB.09.06

  7. Push Rod 12VB.15.16

  8. Rocker Arm 12VB.05.10

  9. Exhaust Valve Seat Z12VB.09.45A

  10. Intake Valve Z12VB.4603F

  11. Valve Guide 12VB.01.02C

  12. Valve Spring 12VB.03.00B

  13. Fuel Injector 2000 Series 212.39.00

  14. Pressure Regulating Valve Assembly 6012.98.00

  15. Oil Pump Drive Gear Assembly 12VB.18.00B

  16. Oil Cooler Cover 12VB.21.10

  17. Thrust Washer 12VB.01.25A

  18. Oil Ring 12VB.05.20

  19. Compression Ring 12VB.05.11

  20. O-Ring 12V.01.14

  21. Piston Cooling Nozzle Z12VB.09.20A

  22. Water Pump 12VB.22.00B

  23. Fuel Pump 12VB.12.00

  24. Transmission Gear 12VB.15.11

  25. Cylinder Head 12VB.32.00D

  26. Rubber Pipe PZ12VB.24.10.02 Engine G-12V190BPZL

  27. Timing Gear 12VB.01.09

  28. Exhaust Elbow 12VB.46.80FA

  29. Intake Elbow 12VB.46.100F

  30. Front Exhaust Pipe 12VB.46.70FA

  31. Front Intake Pipe 12VB.46.90F

  32. Upper Thrust Washer 12VB.01.21A

  33. Lower Thrust Washer 12VB.01.22A

  34. Piston 12VB.05.01C

  35. Fuel Injection Drive Assembly 12VB.15.00

  36. Valve Guide Sleeve 12VB.01.14C

  37. Pushrod 12VB.03.18

  38. Valve Tappet 12VB.08.10.14

  39. Air Intake Manifold 12VB.08.10.16

  40. Exhaust Valve Seat Z12VB.09.04A

  41. Valve Seat Z12VB.09.47

Jinan diesel engine JICHAI POWER G12V190PZL1 12V190 series drilling engine 2
